DUAL BELT CLUTCH

SHIELDS ARE REMOVED TO SHOW THE DUAL BELT CLUTCH WHICH IS THE PRIMARY DRIVE SOURCE. THE EMERGENCY STOP MECHANISM IS BUILT INTO THE DRIVE UNIT AND CAN BE ACTIVATED FROM THE FRONT, SIDES OR REAR OF THE BOX. A SEPARATE CLUTCH ALLOWS YOU TO START AND CLEAR THE BEATERS BEFORE YOU START THE MAIN APRON CONVEYORS. A SIMPLE TROUBLE-FREE VARIABLE SPEED DRIVE LETS YOU MATCH JUST THE RIGHT UNLOAD SPEED TO THE CROP TYPE, LOAD CONDITION AND BLOWER CAPACITY. MAIN APRON UNLOAD RATE IS VARIABLE AND RANGES FROM 9'' UP TO 11'6''/MINUTE.

3-18'' 4 BAR HD BEATERS

H&S USES THREE - 18'' 4 BAR H.D. SPIRAL TYPE BEATERS - NOT AUGERS. AGGRESSIVE IN HANDLING TOUGH MATERIAL, THEY ARE EVEN FEEDING. ALL THREE BEATERS ARE MOUNTED IN THE HEAD, NOT AUXILIARY PANELS IN THE BOX. BEATER SHAFTS ARE 1 1/4'' EQUIPPED WITH GREASABLE BEARINGS.

AUTOMATIC TAILGATE LOCK AND UNLOCK

 ONCE THE TAILGATE SAFETY LOCK IS RELEASED, THE SELF-LOCKING MECHANISM UNLOCKS AUTOMATICALLY WHILE UNLOADING AND LOCKS SHUT WHEN THE TAILGATE CLOSES.

CROSS Z-IRON

ALL INDUSTRIAL FORAGE BOXES FEATURE CROSS Z-IRON. CROSS Z'S ARE WELDED TO THE SIDE CHANNELS INLINE WITH STAKES FOR ADDED STRENGTH.

OPTIONAL GRAIN HOPPER AND FRONT ENCLOSURE

ALUMINIZED FRONT AND REAR UNLOAD INDUSTRIAL BOX WITH OPTIONAL GRAIN HOPPER, FRONT ENCLOSURE AND FOLD DOWN EXTENSION.

REAR UNLOAD DRIVE SYSTEM

AN OPTIONAL REAR UNLOAD DRIVE SYSTEM WITH A QUICK CHANGE PIN IS AVAILABLE ON ALL HDNR FORAGE BOXES.

OPTIONAL GRAIN HOPPER

AN OPTIONAL GRAIN HOPPER GRAVITY UNLOAD FOR SMALL GRAINS IS AVAILABLE FOR WIDE BODY BOXES WITH A TOP HINGED GATE.

FRONT-TO-REAR ELECTRIC ROLL TARP

THE OPTIONAL FRONT-TO-REAR ELECTRIC ROLL TARP IS A NICE FEATURE TO KEEP THAT VALUABLE FORAGE FROM BLOWING OUT DURING TRANSPORT.

SIDE TO SIDE ELECTRIC ROLL TARP

SHOWN WITH THE OPTIONAL HEAVY-DUTY SIDE-TO-SIDE ELECTRIC ROLL TARP.
